QYCZ0.5-10

Detail

Hydraulic hose: 2 - 10 - 43MPa double - layer steel mesh pipe

Guide rail: 5mm flat plate is bent to make the guide rail

Outrigger: 100x50x3.75mm rectangular tube matching

Spraying treatment: use electrostatic powder spraying

Hydraulic oil: 46# Great Wall anti-wear hydraulic oil

Lifting speed: 4-6 m/min, adjustable falling speed

Scissor rod: 120x60x3.75mm rectangular tube

Rust removal: shot blasting, sand blasting

Chassis: 100x50x3.75mm rectangular tube

Shaft pin: 45# round steel, galvanized

Control form: up and down control

Pumping station: Anshan Lisheng

Oil cylinder: HSG80/50 1-4 pieces

Table: 3mm flat plate bending

Tires: 3 pieces pneumatic tires

Power and voltage: DC48V

Distribution box: Delixi

High Performance

1. Wide working table

2. High bearing capacity

3. Multiple people can work at the same time

4. Adopt high-strength manganese steel structure

5. It is applicable to site, plant, station, airport, lifting equipment maintenance, field power facilities maintenance, steel frame structure plant maintenance, etc.
